3. Startup and shutdown operation
(1) Start up: short press the power button, the indicator light is on, and the machine is in
standby mode.
(2) Shutdown: press and hold the power button for more than 2 seconds, and the indicator
light will be off and the machine shut off.
(3) DC power switch and AC power switch are integrated in the interaction LCD screen(Fig-
ure 1),press“DC ON/OFF”button and “AC ON/OFF”button on the screen to turn on/off the
DC /AC output.
4. How to use the touch screen
Interaction LCD screen(Information Vision) supports below functions:
(1) Real time display of voltage, current, power, temperature and state of charge and
discharge.
(2) The user can adjust the output voltage, frequency, charging mode, power consumption
mode and time information according to the setting column.
(3) Support energy-saving, and enable Super ECO mode to save more than 30% of useless
energy loss.
(4) Support users to view fault information, historical fault information, software version
independently.
BMS Over current or short circuit protection
BMS Startup timeout
Normal startup
Normal shutdown
Turn off after the indicator light flashes
The indicator light flashes and not shut down
The indicator light on
The indicator light off
The LED indicator lamp status warning
- 04 -
