© 2016 Blum, Inc. Subject to technical modifications without notice
20
C Activating synchronization
Up to three drive units can be synchronized allowing them to move
simultaneously. This function is required for several cabinets with one
wide front.
Press and hold the <SYNC> button on the 1st drive unit until
the LED flashes
Press and hold <SYNC> on the 2nd drive unit until the LEDs on
both synchronized drive units light up continuously
NOTE: Repeat steps 1 and 2 for all additional drive units
1 2
D Activating collision avoidance
To avoid the collision of door fronts, drive units (six maximum) are
linked so that only one door can be opened at a time. A door front is
prevented from opening as long as a linked door front remains open.
Press and hold the <COLL>
button on the 1st drive unit
until the LED flashes
Close the door manually
Manually open the door of
the unit to be linked
Press and hold <COLL> on
the 2nd drive unit until the
LED lights up continuously
(the same will happen in the
first cabinet)
NOTE: Repeat steps 1 through 4 for all additional cabinets
1 2 3 4
Additional FeaturesSERVO-DRIVE for
AVENTOS
