BLUM SERVO-DRIVE User Manual

2a
2b
< 3 s
> 3 s
2a
2b
< 3 s
> 3 s
2
15
EN
EN
SERVO-D RIVE
Instruction leaet
1) Press (do not pull) the front
➢ The door (refrigerator or dishwasher)
will open slightly for 2.5 sec
2a) User utilises opening to grip door
➢ Continues opening process
2b) User does not touch door
➢ Door closes again
Pressing the handle-less front will trigger the electromechanical opening of SERVO-DRIVE flex.
Electrical motion support system
The following parameters must be observed to ensure the error-free functioning of
SERVO-DRIVE flex:
• Blum distance bumpers must be attached to the front to ensure the required triggering signal (2 mm)
between the pull-out unit and the cabinet.
• No items should be positioned between the pull-out element and the cabinet back
and/or SERVO-DRIVE.
