C66CS/C88CS USER MANUAL
Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk
21
COMMAND ACTION
EDID SAVE zz
Save External EDID Into Slot zz
zz = 19 User EDID 1
zz = 20 User EDID 2
EDID xx DF zz
Change EDID For Input xx
xx = Input (00 refers to ALL inputs, 02 = input 2 etc)
zz = EDID as shown below
00: HDMI 1080p@60Hz, Audio 2CH PCM (default)
01: HDMI 1080p@60Hz, Audio 5.1CH DTS/DOLBY
02: HDMI 1080p@60Hz, Audio 7.1CH DTS/DOLBY/HD
03: HDMI 1080i@60Hz, Audio 2CH PCM
04: HDMI 1080i@60Hz, Audio 5.1CH DTS/DOLBY
05: HDMI 1080i@60Hz, Audio 7.1CH DTS/DOLBY/HD
06: HDMI 1080p@60Hz/3D, Audio 2CH PCM
07: HDMI 1080p@60Hz/3D, Audio 5.1CH DTS/DOLBY
08: HDMI 1080p@60Hz/3D, Audio 7.1CH DTS/DOLBY/
HD
09: HDMI 4K@60Hz 4:2:0/4K@30Hz 4:4:4, Audio 2CH
PCM
10: HDMI 4K@30Hz 4:2:0/4K@30Hz 4:4:4, Audio 5.1CH
DTS/DOLBY
11: HDMI 4K@30Hz 4:2:0/4K@30Hz 4:4:4, Audio 7.1CH
DTS/DOLBY/HD
12: HDMI 4K@60Hz 4:4:4, Audio 2CH PCM
13: HDMI 4K@60Hz 4:4:4, Audio 5.1CH DTS/DOLBY
14: HDMI 4K@60Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
15: DVI 1280x1024@60Hz, Audio None
16: DVI 1920x1080@60Hz, Audio None
17: DVI 1920x1200@60Hz, Audio None
18: HDMI 1920x1200@60Hz, Audio 2CH PCM/6CH
PCM
19: User EDID 1
20: User EDID 2
EDID xx CP yy
Copy EDID From Output yy To Input xx
xx = 00 : All Inputs
xx = [01-08] Inputs 1 - 8
yy = [01-08] : Output 1 - 8
PRESET pp SAVE
"Save Current Output Connections To Preset pp
Config
pp = [01-09] : Preset 1 - 9"
PRESET pp SET Set Preset pp Config
PRESET pp CLR Delete Preset pp Config
POCOUT xx ON Set PoC On on ouput xx
POCOUT xx OFF Set PoC O on ouput xx
OUT xx FR yy
Set Output xx From Input:yy
xx = 00 : All Outputs
xx = [01-08] : Output 1 - 8
yy = [01-08] : Input 1 - 8
OUT xx ON
Set Output xx On
xx = 00 : All Outputs
xx = [01-08] : Output 1 - 8
OUT xx OFF
Set Output xx O
xx = 00 : All Outputs
xx = [01-08] : Output 1 - 8
OUT xx EH/ET
Set OUTPUT:xx use HDMI/HDBT EDID
xx=[00]: All OUTPUT port, [01...08]: OUTPUT port
yy=[01...08]: INPUT port
COMMAND ACTION
IN xx CECOK Confirm operation (Enter) on input xx
IN xx CECUP Up on input xx
IN xx CECDOWN Down on input xx
IN xx CECLEFT Le on input xx
IN xx CECRIGHT Right on input xx
IN xx CECRETURN Back to submenu on input xx
IN xx CECEXIT Exit on input xx
IN xx CECVOLUP Volume up on input xx
IN xx CECVOLDOWN Volume down on input xx
IN xx CECPLAY Play on input xx
IN xx CECSTOP Stop on input xx
IN xx CECPAUSE Pause on input xx
IN xx CECRECORD Record on input xx
IN xx CECREWIND Rewind on input xx
IN xx CECFF Fast forward on input xx
IN xx CECFWD Forward on input xx
IN xx CECBWD Backward on input xx
IN xx CECPOFF Power o on input xx
IN xx CECPON Power on on input xx
OUT xx CECVOLUP Volume up on output xx
OUT xx CECVOLDOWN Volume down on output xx
OUT xx CECMUTE Mute toggle on output xx
OUT xx CECPOFF Power o on output xx
OUT xx CECPON Power on on output xx
OUT xx CECOK Confirm operation (Enter) on input xx
OUT xx CECUP Up on input xx
OUT xx CECDOWN Down on input xx
OUT xx CECLEFT Le on input xx
OUT xx CECRIGHT Right on input xx
OUT xx CECRETURN Back to submenu on input xx
OUT xx CECEXIT Exit on input xx
OUT xx CECPLAY Play on input xx
OUT xx CECSTOP Stop on input xx
OUT xx CECPAUSE Pause on input xx
OUT xx CECRECORD Record on input xx
OUT xx CECINPUT yy
CEC Input channel yy selection on output xx
xx=00: Select All Output Port
xx=[01...08]: Output 1-8
yy=[01…08]: Select One HDMI In Port 1-8
RS-232 Configuration and Telnet Commands
