C66CS/C88CS USER MANUAL
Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk
03
Our Contractor 8x8 HDBaseT™ CSC Matrix oers unprecedented performance and
value for the custom installation market. The C66CS and C88CS are 4K 60Hz 4:4:4
HDCP 2.2 Matrix units deliveringHDMI, bi-directional IR and PoC up to lengths of
70m (at 1080p) over a single CAT cable.
These Matrix products also provide advanced features including simultaneous
HDBaseT™ / HDMI on output 1 and a web browser interface module for control
and configuration of the unit.
Introduction
FEATURES:
• Advanced HDBaseT™ technology oering uncompressed video and audio with zero latency
• Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR*
• Features 6 x (C66CS) or 8 x (C88CS) HDMI inputs which can be independently routed to 6 x (C66CS) or 8 x (C88CS)
HDBaseT™ outputs
• Output 1 features simultaneous HDMI and HDBaseT™ output
• Video down-conversion on HDBaseT™ outputs allowing a display only capable of supporting lower video
resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K
UHD resolution on remaining video outputs
• Supports 4K 60Hz 4:4:4 UHD video up to 40m
• Extends HDMI up to a distance of 70m over single CAT cable
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD
Master Audio transmission
• Web interface module for control and configuration of the Matrix
• Supports bi-directional IR on all HDBaseT™ outputs
• Control via front panel, IR, RS-232, TCP/IP and free iOS / Android Apps
• Supports PoC (Power over Cable) to power compatible HDBaseT™ Receivers
• Supplied with Blustream IR Receivers and Emitters
• 3rd party drivers available for major control systems
• 1U Design for 19” rack mount integration- mounting kit included
• Advanced EDID management
• HDCP 2.2 compliant
* CSC feature compatible with RX70CS receivers only (sold separately). The HDMI ARC and Optical Audio Return
functionality of the RX70CS HDBaseT™ Receivers is not compatible with the C66CS or C88CS Matrix products.
