MFP72 USER MANUAL
10
www.blustream.co.uk
NO. Command Action
1 ? Print Help Information
2 HELP Print Help Information
3 STATUS Print System Status And Port Status
4 PON Power On, System Run On Normal State
5 POFF Power O, System Run On Power Save State
6 IRON/OFF Set System IR Control On Or O
7 KEYON/OFF Set System KEY Control On Or O
8 DBGON/OFF Set Debug Mode On Or O
9 BEEPON/OFF Set Onboard Beep On Or O
10 RESET
Reset System To Default Setting
(Should Type “Yes” To Confirm, “No” To Discard)
11 OUTxxFRyy
Set OUTPUT:xx From INPUT:yy
xx=00: Select All OUTPUT Port
xx=[01...02]: Select One OUTPUT Port
yy=[01...04]: HDMI Input 01 ~ 04
yy=AV: AV Input( Output 02 Only )
yy=COMP: Component Input( Output 02 Only )
yy=VGA: VGA Input( Output 02 Only )
12 OUTSP/MX Set OUTPUT To Splitter or Matrix Mode
13 OUTRESrr
Set Scaler Output Resolution
rr=01: 1080P@50Hz
rr=02: 1080P@60Hz
rr=03: 720P@60Hz
rr=04: 720P@50Hz
rr=05: 1280x1024@60Hz
rr=06: 1024x768@60Hz
rr=07: 1360x760Hz
rr=08: 1440x900@60Hz
rr=09: 1680x1050@60Hz
14 EDIDxxCPyy
Set Input:xx EDID Copy From Output:yy yy=[00]:
yy=[01...08]
15 EDIDxxDFzz
Set Input:xx EDID To Default EDID:zz
xx=00: Select All INPUT Port
xx=[01...04]: Select One INPUT Port
yy=[01...02]: Select One OUTPUT Port
zz=00: HDMI 1080p@60Hz, Audio 2CH PCM
zz=01: HDMI 1080p@60Hz, Audio 5.1CH PCM/DTS/DOLBY
zz=02: HDMI 1080p@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=03: HDMI 1080i@60Hz, Audio 2CH PCM
zz=04: HDMI 1080i@60Hz, Audio 5.1CH PCM/DTS/DOLBY
zz=05: HDMI 1080i@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=06: HDMI 1080p@60Hz/3D, Audio 2CH PCM
zz=07: HDMI 1080p@60Hz/3D, Audio 5.1CH PCM/DTS/DOLBY
zz=08: HDMI 1080p@60Hz/3D, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=09: HDMI 4K2K, Audio 2CH PCM
zz=10: HDMI 4K2K, Audio 5.1CH PCM/DTS/DOLBY
zz=11: HDMI 4K2K, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=12: DVI 1280x1024@60Hz, Audio None
zz=13: DVI 1920x1080@60Hz, Audio None
zz=14: DVI 1920x1200@60Hz, Audio None
16 AUDSCAORG Scaler Audio Input Follow Port Selection
17 AUDSCAANA Scaler Audio Input From Analog L/R Signal
18 AUDxx
Set Scaler Audio Volume
xx=[00...30]: Volume Value
RS232 and Telnet Commands
MFP72
PIN Assignment
1 NC
2 Tx
3 Rx
4 NC
5 GND
6 NC
7 NC
REMOTE CONTROL CONSOLE
PIN Assignment
1 NC
2 Rx
3 Tx
4 NC
5 GND
6 NC
7 NC
RS-232 Pin Assignment
Baud Rate: 57600 bps
Data Bit: 8-bit
Parity: None
Stop Bit: 1-bit
Flow Control: None
