MFP72 USER MANUAL
08
www.blustream.co.uk
Example Schematic
MFP72
Optical Digital
RS232
HDMI
Coaxial Digital
Speaker Cable
Analogue L/R Audio
IR Cable
DISPLAYDISPLAY
MAXIMUM 4 SOURCES
Control
Processor
VCR
