BMC M1 Mini User Manual

M1 Mini User Manual
28 / 32
Guidance and manufacturer's declaration - electromagnetic immunity
The device is intended for use in the electromagnetic environment specified below. The
customer or the user of the device should assure that it is used in such an environment.
Immunity Test
IEC 60601 Test Level
Compliance Level
Conducted RF
IEC 61000-4-6
3 V 0.15 MHz ～ 80 MHz
6 V in ISM bands between
0.15 MHz and 80 MHz
3 V 0.15 MHz ～ 80 MHz
6 V in ISM bands between 0.15 MHz
and 80 MHz
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz to 2.7 GHz
10 V/m
80 MHz to 2.7 GHz
Note 1: At 80 MHz and 800 MHz, the higher frequency range applied.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects and people.
a
Field strengths from fixed transmitters, such as base stations for radio (cellular /
cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast
and TV broadcast cannot be predicted theoretically with accuracy. To assess the
electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey
should be considered. If the measured field strength in the location in which the device is
used exceeds the applicable RF compliance level above, the device should be observed to
verify normal operation. If abnormal performance is observed, additional measures may
be necessary, such as re-orienting or relocating the device.
b
Over the frequency range 150 kHz to 80 MHz, the field strengths should be less than 10
V/m.

BMC M1 Mini Specifications

General

Category	Medical Equipment
Pressure Range	4-20 cmH2O
Type	CPAP
Weight	0.8 kg
Humidifier	Integrated
Power Source	AC power adapter, optional battery pack
