RESmart GII BPAP System Y / U Series User Manual V2.1
6 / 42
Pressure Display Accuracy
± (0.8 hPa4%)
Static Pressure Stability
± 0.5 hPa
Ramp
The ramp time ranges from 0 to 60 minutes.
Sound Pressure Level
< 30 dB, when the device is working at the pressure of 10 hPa.
Sound Power Level
< 38 dB, when the device is working at the pressure of 10 hPa.
Maximum Flow
Test Pressure (hPa)
4
15
20
25
Measured Pressure at the
Patient Connection Port
(hPa)
3
14
19
24
Average Flow at the Patient
Connection Port (L/min)
93.2
98.1
98.5
99.1
SpO
2
Range: 0 100%
The margin of error for SpO
2
between 70% and 100% is ± 3%. No strict accuracy
requirements for SpO
2
below 70%.
Pulse Rate
Range: 40 240 BPM
Margin of Error: ± 1%
Wavelengths
Red: 663 nanometers
Infrared: 890 nanometers
Maximal Optical Output Power
Less than 1.5 mW maximum average.
Tube
Length: 6 ft. (1.83 m)
The Form and the Dimensions of the Patient Connection Port
The 22 mm conical air outlet complies with ISO 5356-1.
