RESmart GII BPAP System Y / U Series User Manual V2.1
5 / 42
5. Specifications
Device Size
Dimensions: 170 mm × 180 mm × 118 mm, or 290 mm × 180 mm × 134 mm (with the
humidifier)
Weight: 1.5 kg, or 2.5 kg (with the humidifier)
Product Use, Transport and Storage
Operation Transport and Storage
Temperature: 5°C to 35°C (41˚F to 95˚F) -25°C to 70°C (-13˚F to 158˚F)
Humidity: 15% to 93% Non-condensing 15% to 93% Non-condensing
Atmospheric Pressure: 760 to 1060 hPa 760 to 1060 hPa
Mode of Operation
Continuous
Work Mode
CPAP, S, AutoS, AutoCPAP, S/T, T
SD Card
SD card can record patient data and fault information.
AC Power Consumption
100 – 240 V ～ 2 – 1 A, 50 / 60 Hz
Main Device offer to USB Communications Port
5 V 2.0 A
Main Device offer to Humidifier
24 V 1.5 A
Type of Protection against Electric Shock
Class II Equipment
Degree of Protection against Electric Shock
Type BF Applied Part
Degree of Protection against Ingress of Water
IP22
Pressure Range
IPAP: 4.0 ～ 20.0 hPa (only applies to Y-20T, U-20T); 4.0 ～ 25.0 hPa (only applies to Y-25T,
U-25T); 4.0 ～ 30.0 hPa (only applies to Y-30T, U-30T, U-30AT); in 0.5 hPa increments.
EPAP: 4.0 ～ 20.0 hPa (only applies to Y-20T, U-20T); 4.0 ～ 25.0 hPa (only applies to
Y-25T, Y-30T, U-25T, U-30T, U-30AT); in 0.5 hPa increments.
CPAP mode: 4.0 ～ 20.0 hPa
Under single fault conditions, ≤ 30 hPa for CPAP mode, ≤ 40 hPa for the rest modes.
