RESmart GII BPAP System Y / U Series User Manual V2.1
12 / 42
• When the insulation layer of the SpO
2
probe cable is damaged, do not connect the probe to
the patient.
• Please contact BMC to buy the SD card if you need it.
10. System Features
Humidifier Indicator
Mute Button
Knob
Ramp Button
Display Screen
Power Indicator
Air Outlet
Humidifier Connector
Shield
Fig. 10-1
Name
Function
Humidifier
Indicator
Indicate the humidity level. There are five levels in total. The number of
blue indicator lights that light up is directly proportional to the humidity
level. If none of the indicator lights light up, it means the humidifier is
turned off
Mute Button
Press this button to mute the alert. However, if the problem causing the
alert is not solved, the alert will sound again two minutes later
Knob
Start treatment and adjust device settings
Ramp Button
Enable the Ramp feature
Display Screen
Display menus for operation, messages, monitoring data, etc.
Power Indicator
Indicate the power supply status with the green indicator light
Air Outlet
Deliver pressurized air; connected to the tube or the air inlet of the
humidifier
Humidifier
Connector
Provide power to the humidifier which is connected to the main device
Shield
Connect the humidifier to the main device after this shied is removed
