The photocell elements should be installed so that the closed curtain cuts the beam.
Action Description LED
5s
Close the door to the limit switch.
Push button panel led: steady green.
Press PRG for 5s.
Button panel led: flashing green/red.
Pedestrian press
Button panel led: flashing red.
Pedestrian press
Button panel led: steady red.
Pedestrian press
Button panel led: flashing green/red.
Closed door.
Push button panel led: steady green.
PEDESTRIAN (LIMIT SWITCH/ENCODER)
