BMPRO ControlNode102 User Manual

25
SPECIFICATIONS
J35 BATTERY MANAGEMENT SYSTEM J35A J35B J35C J35D
Input Voltage Range 240 VAC ± 10% (nominal), 50-60 Hz
Input Surge
< 40A (cold start)
Output Current (Load + Battery Current) 20A 35A 35A 35A
Factory Set Voltage (Float Voltage) 13.65 V +/0.1 V
Output Ripple Voltage
< 150 mV
Over Voltage Protection
< 18V
Over Current Protection (Load + Battery
Current)
20-25A 35-38A 35-38A 35-38A
Battery Current Limit 15A 30A
Low Voltage Disconnect Lead Acid 10.5 ± 0.2V
Low Voltage Disconnect LiFePO4
-
11.5 ±
0.2V
Battery Drain (when in Storage Mode)
< 8mA
AC/DC Efficiency
> 83 %
Cooling Fan Thermally controlled
Solar Input Current
– <20A <27A <27A
Solar Input Voltage – 15-25V 15-25V 15-25V
Ambient Temperature 0-50°C
Communication CAN Bus
Weight 2 kg
Standards
Safety: IEC60335-2-29, IEC62109-1,UL458,
CSA C22.2 No.107-1, EMC: CISPR 14,
IEC61000-3-2, IEC61000-3-3 Approvals: RCM,
UL, cUL
CONTROLNODE102
Input Voltage 8-15 V DC
Battery Drain
< 21 mA
Ambient Temperature 0–50ºC
Cable Length 0.5m
