10© BMW AG, München 01 29 0 406 372 12.2005 (Z/Z)
3. Connection diagram
B Voltage supply D Connection wiring harness (left seat)
B1 WS 4-pin plug D1 8-pin round plug, SW
B2 WS 4-pin plug D2 8-pin round plug, SW
B3 WS 3-pin plug D3 8-pin round plug GE/BL
D4 8-pin round plug, BL
C Multimedia changer AV adapter
C1 8-pin round plug, GN E Connection wiring harness (right
seat)
C2 Black 4-pin plug E1 8-pin round plug, SW
C3 Cinch socket GE E2 8-pin round plug, SW
C4 Cinch socket RT E3 8-pin round plug RT/GE
C5 Cinch socket WS E4 8-pin round plug RT
J
C
D
H
H
G
E
G
F
F
U
L
D3
E3
B2
L5
L1-L3
C3-C5
L4
C2
J2
J1
B3
B1
E2
E1
F3
F4
F1
F2
G2
AA1
AA1 H2
G1
G2
G1
H1
H2
H1
B
F2
F1
F3
D2
D1
F4
AA AA
D4
E4
C1
061 0235 Z
