F48�Information�and�Communication
3.�Speaker�Systems
9
3.1.�Overview
The�speaker�systems�in�the�F48�are�available�in�three�specification�levels:
• Hi-fi�system�(SA676)
• Harman�Kardon®�hi-fi�system�(SA674)
3.2.�Components
3.2.1.�Hi-fi�system
The�hi-fi�system�in�the�F48�is�standard�equipment�(SA676).�The�hi-fi�system�comprises�7�speakers,
with�an�overall�power�of�205Watt.
The�amplifier�of�the�hi-fi�system�is�not�connected�to�any�bus�system.
Components
F48�system�components�of�hi-fi�system
Index Explanation
1 Mid-range�speaker,�front�center
2 Mid-range�speaker,�front�right
3 Bass�speaker,�right
4 Mid-range�speaker,�rear�right
5 Amplifier�(AMP)
6 Mid-range�speaker,�rear�left
7 Bass�speaker,�left
8 Mid-range�speaker,�front�left
