F48�Information�and�Communication
2.�Headunits
5
Index Explanation
1 Fuses�in�the�power�distribution�box�in�the�passenger�compartment
2 Body�Domain�Controller�(BDC)
3 Central�information�display�(CID)
4 Headunit
5 Bluetooth�antenna
6 USB�audio�interface
7 Controller�(CON)
8 K-CAN�terminator
9 Microphone,�driver's�side
10 Steering�column�switch�cluster�(SZL)
11 Instrument�cluster�(KOMBI)
2.2.2.�Navigation�systems
The�customer�has�the�option�of�ordering�two�navigation�systems.�The�optional�equipment�Navigation
(SA6UN)�and�the�optional�equipment�Navigation�Plus�(SA6UP).�The�headunit�is�identical�for�the�two
equipment�specifications.�With�the�optional�equipment�Navigation�Plus�(SA6UP),�the�F48�receives
additional�equipment,�for�example�a�touch�controller�and�8.8"�central�information�display,�as�well�as�a
Head‐Up�Display.
Rear�view,�Headunit�with�navigation
Index Explanation
1 Main�connector
2 Not�for�US
3 Not�for�US
4 AM/FM1�antenna
5 FM2�antenna
