F97/F98�Complete�Vehicle
5.�Chassis�and�Suspension
69
Index Explanation
1 M�Dynamic�Stability�Control�(M�DSC)
2 Wheel�speed�sensor,�front�left
3 Vertical�acceleration�sensor,�front�left
4 Ride�height�sensor,�front�left
5 EDC�control�valve,�front�left
6 Auxiliary�coolant�pump,�heating
7 Digital�Motor�Electronics�(DME)
8 PT-CAN�terminating�resistor
9 Electronic�transmission�control�(EGS)
10 M�Servotronic�(M�EPS)
11 M�transfer�box�(M�VTG)
12 EDC�control�valve,�front�right
13 Front�right�vertical�acceleration�sensor
14 Wheel�speed�sensor,�front�right
15 Fuse�30B�(power�distribution�box,�front)
16 Body�Domain�Controller�(BDC)
17 Fuse�30F�(power�distribution�box,�front)
18 Fuse�30B�(power�distribution�box,�front)
19 M�Vertical�Dynamic�Platform�(M�VDP)
20 Wheel�speed�sensor,�rear�right
21 Rear�right�vertical�acceleration�sensor
22 EDC�control�valve,�rear�right
23 Power�distribution�box,�rear
24 Regulated�M�rear�axle�differential�lock�(M�GHAS)
25 K-CAN4�terminating�resistor
26 EDC�control�valve,�rear�left
27 Ride�height�sensor,�rear�left
28 Rear�left�vertical�acceleration�sensor
29 Wheel�speed�sensor,�rear�left
30 Advanced�Crash�Safety�Module�(ACSM)
31 Controller�(CON)
32 M�gear�selector�switch�(M�GWS)
33 M�drive�dynamic�control�switch
34 PT-CAN2�terminating�resistor
35 Head�Unit�HU�(M-specific)
