General information
Vehicle features and
options
This chapter describes all standard, country-spe‐
cific and optional features offered with the series.
It also describes features that are not necessarily
available in your vehicle, e. g., due to the selected
options or country versions. This also applies to
safety-related functions and systems. When us‐
ing these functions and systems, the applicable
laws and regulations must be observed.
Control elements
Buttons and functions
Button Function
Press: switches sound out‐
put on/off.
Turn: adjusts the volume.
Change the entertainment
source.
Press once: changes the
station/track.
Press and hold: fast for‐
ward/rewind the track.
Programmable memory
buttons.
ConnectedDrive.
Depending on the vehicle
equipment, programmable
memory button 8 is re‐
placed with this button.
Button Function
Change waveband/satellite
radio.
Eject CD/DVD.
Sound output
Safety information
WARNING
A high sound output volume can damage your
hearing. There is a risk of injury. Do not adjust
the volume too high.
Volume and sound output
▷ Turn the button to adjust the
volume.
▷ Press the button to switch off
the sound output. Pressing
the button again restores the
previous volume setting.
Audio recording playback is stopped during mut‐
ing.
Entertainment sources
General information
Possible entertainment sources:
▷ Radio, refer to page 41.
▷ Audio CD, refer to page 50.
▷ Video DVD, refer to page 59.
▷ Music collection, refer to page 52.
Seite 36
ENTERTAINMENT
General information
36
