clockwise, and flip the cap

open.

Refuel with fuel of the grade

stated above; do not fill the

tank past the bottom edge of

the filler neck.

NOTICE

When refuelling after running on

reserve, make sure that you top

up the tank to a level above re-

serve, as otherwise the new level

will not be registered and the

FUEL! warning indicating that

the level is down to reserve will

not be switched off.

NOTICE

The “usable fuel capacity” spe-

cified in the technical data is the

quantity that the fuel tank could

hold if it had been run dry and

the engine had cut out due to a

lack of fuel.

Usable fuel capacity

approx. 20 l

Fuel reserve

approx. 4 l

Press the fuel tank cap down

firmly to close.

Remove the ignition key and

close the protective cap.

Securing motorcycle

for transportation

Make sure that all components

that might come into contact

with straps used to secure the

motorcycle are adequately pro-

tected against scratching. Use

adhesive tape or soft cloths, for

example, for this purpose.

ATTENTION

Vehicle topples to side when

being lifted on to stand.

Risk of damage to parts if vehicle

topples.

110

Riding

Questions and Answers:

Need help?

Do you have a question about the BMW S 1000 XR and is the answer not in the manual?

BMW S 1000 XR Specifications

General

Displacement	999 cc
Power	165 hp (121 kW) at 11, 000 rpm
Fuel System	Electronic fuel injection
ABS	Standard
Traction Control	Standard
Torque	114 Nm at 9, 250 rpm
Transmission	6-speed
Rear Suspension	Aluminum 2-sided swing arm
Front Brakes	Dual disc brakes
Rear Brakes	Single disc brake
Seat Height	840 mm
Fuel Capacity	20 liters
Dry Weight	226 kg
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Front Suspension	Upside-down telescopic fork, adjustable compression and rebound damping
