BMW S 1000 XR User Manual

The power supply to the sock-
ets is switched off no more
than 15 minutes after the igni-
tion is switched off, in order to
prevent overloading of the on-
board electrics. Low-wattage
electrical accessories might not
be recognised by the vehicle’s
electronics. In such cases,
power sockets are switched
off very shortly after the ignition
is turned off.
If the battery charge state is
too low to maintain the mo-
torcycle's start capability, the
power sockets are switched off.
The power sockets are also
switched off when the max-
imum load capability as stated
in the technical data is ex-
ceeded.
Cases
Open cases
with case holders left / right
OE
Turn the key 1 to position
OPEN.
Pull the grey release leaver 2
(OPEN) all the way up and
simultaneously open the case
lid.
Closing cases
with case holders left / right
OE
Turn the key 1 to position
OPEN.
Press catches 2 of the case
lid into retainers 3. Check that
nothing is trapped between the
lid and the case.
Pull the grey release lever 4
(OPEN) all the way up and
simultaneously open the case
lid.
The lid engages with an aud-
ible click.
Turn key 1 in the case lock
to the position in which it is
parallel with the direction of
travel and remove the key.
9
169
z Accessories

BMW S 1000 XR Specifications

General

Displacement	999 cc
Power	165 hp (121 kW) at 11, 000 rpm
Fuel System	Electronic fuel injection
ABS	Standard
Traction Control	Standard
Torque	114 Nm at 9, 250 rpm
Transmission	6-speed
Rear Suspension	Aluminum 2-sided swing arm
Front Brakes	Dual disc brakes
Rear Brakes	Single disc brake
Seat Height	840 mm
Fuel Capacity	20 liters
Dry Weight	226 kg
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Front Suspension	Upside-down telescopic fork, adjustable compression and rebound damping
