BNF Blade 270 CFX - Table of Contents; Box Contents

3
EN
Table of Contents
Box Contents
Box Contents ....................................................................3
First Flight Preparation ......................................................4
Flying Checklist ................................................................4
Low Voltage Cutoff (LVC) ...................................................4
Transmitter Setup .............................................................4
Installing the Flight Battery ...............................................7
Transmitter and Receiver Binding ......................................7
Throttle Hold .....................................................................8
Control Tests .....................................................................8
Pre-Flight Checklist ..........................................................9
Flying the Blade 270 CFX .................................................9
Gyro Gain Adjustment .....................................................10
Blade Helicopter Belt Tension .........................................10
Post-Flight Inspections and Maintenance ........................11
Troubleshooting Guide ....................................................11
Exploded View ................................................................13
Parts List ........................................................................15
Optional Parts List ...........................................................15
Limited Warranty ............................................................15
Warranty and Service Contact Information ......................16
FCC Information ..............................................................17
IC Information .................................................................17
Compliance Information for the European Union ..............17
• Blade
®
270 CFX
• Hook and loop battery strap
Length 560mm
Height 190mm
Flying Weight 626 g
Main Rotor Diameter 620mm
Tail Rotor Diameter 160mm
Specifi cations
Components
Airframe
Blade
®
270 CFX Included
Motors
Brushless Outrunner, 2300Kv Installed
Receiver
AR7210BX Installed
ESC
Castle Creations Talon 35 - Amp ESC Installed
Swash Servos
Digital Cyclic Servo 12 g Metal Gear Installed
Tail Servo
Digital Tail Servo 12 g Metal Gear Installed
Battery
910mAh 6s 22.2V 30c Li-Po (EFLB9106S30) Required
Charger
Li-Po Balancing Charger Required
Transmitter
Full Range DSM2
®
/DSMX
®
technology transmitter (DX6 and up) Required
