SYSTEM SETUP
Model Type HELI
Swash Type Normal
F-Mode Setup
Switch 1 Switch B
Switch 2 Inhibit
Hold Switch Switch H
0
1
Channel Assign
Channel Input
1 Throttle
2 Aileron
3 Elevator
4 Rudder
5 Gear Gyro
6 AUX 1 Pitch
7 AUX 2 AUX 2
Frame Rate
11ms
DSMX
Chan Travel Reverse
THR 111/124 Normal
AIL 100/100 Normal
ELE 100/100 Reverse
RUD 100/100 Normal
GER 100/100 Normal
Chan Travel Reverse
PIT 100/100 Normal
AX2 100/100 Normal
AX3 100/100 Normal
AX4 100/100 Normal
Servo Setup
FUNCTION LIST
DX6, DX7 (Gen 2), DX9, DX18
Panic Mode Operation
Switch A
Pos 0 = Panic Mode Off
Pos 1 = Panic Mode On
Timer
Mode Count Down
Time 4:00
Start Throttle Out
Over 25%
One Time Inhibit
Throttle Curve
Sw (B) Pos Pt 1 Pt 2 Pt 3 Pt 4 Pt 5
N 0 30 30 30 30
17070707070
2 100 100 100 100 100
HOLD 10 10 10 10 10
Pitch Curve
Sw (B) Pos Pt 1 Pt 2 Pt 3 Pt 4 Pt 5
N 30 40 50 75 100
1 0 25 50 75 100
2 0 25 50 75 100
HOLD 0 25 50 75 100
Gyro
Chan Swich (A) Pos
GEAR
0 40%
1 –60%
D/R & Expo
Chan
Switch (F) Pos
D/R ExpoDX6
DX7, 9,
18
AILE
0 0 100/100 +25
1 100/100 +25
1 2 75/75 +25
ELEV
0 0 100/100 +25
1 100/100 +25
1 2 75/75 +25
RUDD
0 0 100/100 +25
1 100/100 +25
1 2 75/75 +25
