Bobcat 2200 Gasoline and Diesel Vehicle Operation & Maintenance Manual Page 41
Rear differential:
Clean and install the drain plug (2) and washer before filling the rear differential with new lubricant
(Figure 32). Tighten the drain plug to 8 ft-lb (10.8 N·m). Use a funnel when filling the differential through the
lubricant level indicator hole (1). See Periodic Lubrication Schedule on page 33. Apply Loctite 567 to the
threads of the level indicator plug and tighten to 21 ft-lb (28 N·m).
ENGINE COOLANT – DIESEL VEHICLES
ENGINE COOLANT LEVEL CHECK
The coolant reserve tank is located under the dashboard next to the brake fluid reservoir (Figure 17). Raise
the access panel located on top of the dashboard to check the coolant level before every operation.
1. Check the coolant level of the reserve tank (2). If the coolant is at or below the LOW mark, add water until
level reaches the FULL mark. If a leak is detected, have it checked by a trained technician. See follow-
ing WARNING.
ý WARNING
• Hot! Coolant reserve tank is pressurized. Do not remove cap when engine is hot.
Figure 32 Rear Differential Lubrication Level
1
2
