11
3) Feed the power cable through the grommet:
- feeding through the back (A)
- feeding through the bottom (B)
4) Connect the cable to the electrical main (100-240VAC power supply).
5) Put the hatch back in place.
A
B
B
A
8Txx or 8NTxx scoreboards
(Only one electronic card for
the 8T120 SOLO)
80xx scoreboards
