Body Champ BRB835 - Hardware and Tool List

BRB835/852/880 Page
3
#05
Carriage Bolt (M10x57mm)
Pre-assembled
[4 pieces]
#37 Bolt (M8x50mm)
[2 pieces]
#06
Arc Washer (M10)
Pre-assembled
[4 pieces]
#07
Cap Nut (M10)
Pre-assembled
[4 pieces]
#41
Lock Knob (M10)
Pre-assembled
[2 pieces]
Tool 2
#34
Cap Nut (M8)
[2 pieces]
#33
Arc Washer (M8)
Pre-assembled
[6 pieces]
#36
Washer (M10)
Pre-assembled
[2 pieces]
#35
Washer (M8)
[8 pieces]
#31
Screw (M5x10mm)
Pre-assembled
[2 pieces]
#16
Carriage Bolt (M8x42mm)
[2 pieces]
#32
Bolt (M8x15 mm)
[10 pieces]
Pre-assembled
[6 pieces]
Tool 1 (S5)
Hardware and Tool List
Bolt
Washer
Nut
Others & Tools (Included)
The following hardware is used to assemble your unit. Please take a moment to familiarize yourself with these
items. PLEASE NOTE : Most of these parts are already pre-assembled on your unit. Do not be alarmed if you
see parts on this page that are not included in your hardware packet.
