A. Attach Back Pad (T) to Angled Support Pillar (E) using:
Two 47 (5/16” x 2 3/4” hex head bolt)
Two 55 (5/16” spring lock washer)
Two 54 (5/16” flat washer)
Note:
Do not over tighten Pad Bolts (47), over tightening will strip the T-nuts pressed into
the wood.
B. Attach Seat Pad (U) to Seat Frame (J) using:
Two 48 (5/16” x 1 3/4” hex head bolt)
Two 55 (5/16” spring lock washer)
Two 54 (5/16” flat washer)
Note:
Do not over tighten Pad Bolts (48), over tightening will strip the T-nuts pressed into
the wood
.
C. Connect the Water Bottle Bracket (31) to the Vertical Support Pillar (D) using:
Two 32 (1/8” x 3/8” screw)
D. Slide the Water Bottle Holder (33) onto the Water Bottle Bracket (31) as shown.
7
Be careful to assemble all components
in the sequence they are presented.
mm
Inch
14
STEP
To Next Page
