Body Solid G1S - Page 25

Selector Rod
Top Bolt
NOTE 1
Check Jam Nut (73)
weekly to be sure it
is tight and locked
onto the Selector
Rod (20).
12
STEP
25
Loosen
Turn and loosen Rubber Stop (35) to take
up space and tighten cable.
Selector Rod Top Bolt (70)
must be threaded a
minumum of 1/2” into the
Selector Rod (20), and
Jam Nut (73) tightened
securely against spring
lock washer (72) to ensure
proper connection.
WARNING
!
!
