Be careful to assemble all components
in the sequence they are presented.
4
STEP
A. Slide Weight Stack Plates (37)* onto Guide Rods (E). Make sure the opening in each Weight
Stack Plate (37), for the Weight Stack Pin (60), is facing for
ward.
*NOTE:
Use fifteen 10lb. plates for a 160lb. weight stack.
Use twenty 10lb. plates for a 210lb. weight stack. See NOTE after Step 1B.
B. Selector Rod Top Bolt (101) and hardware are pre-installed into the Selector Rod (23).
Connect Top Plate (22) to the Selector Rod (23) using:
One 53 (3/8” x 2” socket head bolt)
One 140 (3/8” spring lock washer)
Slide Top Plate (22) and Selector Rod (23) onto Guide Rods (E).
C. Slide two Shaft Collars (12) onto the two Guide Rods (E) as shown.
D. Insert Guide Rods (E) into Rear Arch Post (F), and attach both Rear Arch Posts (F) to Rear Base
Frame (B) using:
Four 44 (1/2” x 3 1/2” hex head bolt)
Eight 73 (1/2” washer)
Four 71 (1/2” nylon lock nut)
E. Slide Shaft Collars (12) up into the Rear Arch Post (F) and turn the Shaft Collar, so it locks onto
the Rear Arch Post (F), Now tighten each Allen Screw (111) in Shaft Collars (12).
NOTE:
Finger tighten all hardware in this step. Do Not
wrench tighten until end of step 3.
To Next Page
