4.3 Adjustment
* To adjust the seat height, slacken the Spring Knob (7) on the vertical post stem on the
Main Frame (16) and pull back Spring Knob (7). Position the vertical post stem for the
desired height so that holes are aligned, then release Spring Knob (7) and retighten it.
* To move the seat forward in the direction of the handlebar or backwards away from it,
loosen Adjusting Knob (21) and Washer (20). Slide Horizontal Seat Post (10) into desired
position. Align holes and then retighten the Adjusting Knob (21).
* To adjust the handlebar, slacken the L Spring Knob (19, 22) and pull both knobs back.
Slide the Handlebar Post (17) along the housing on the Main Frame (16) to the desired
height and, with the holes aligned correctly, tighten the both knobs.
To Next Page
