4 ASSEMBLY
In order to make the assembly of the equipment easier, we recommend that you do not
initially fully tighten the screws and bolts. However, you should make sure that all screws
and bolts are rmly tightened after assembly.
4.1 Package contents
The package contains the parts represented in the illustration. If one of the illustrated parts is
missing, please contact your contract partner.
NO.3 / NO.5 / No. 6
Carriage bolt Set x 4 set
No.19
L Shape Knob x 1pc
No.7
Spring Adjustment Knob x 1pc
No.22
L Shape Knob x 1pc
