B50 Tour Indoor Cycle
9.3 Parts list
No. Description Qty. No. Description Qty.
1 Pedal 1 43 Screw4 1
2 End Cap 1 4 44 Outer Chain Cover 1
3 Carriage Bolt 4 45 Little Chain Cover 1
4 Rear Stabilizer 1 46 Axis 1
5 Flat Washer 4 47 Long Fixing Tube 1
6 Domed Nut 4 48 Short Fixing Tube 1
7 Spring Adjustment Knob 1 49 Inner Chain Cover 1
8 Plastic Sleeve 1 2 50 Belt 1
9 Flat Washer 2 51 Belt Wheel 1
10 Vertical Seat Post 1 52 Screw5 2
11 End Cap 1 2 53 Nut 1
12 Seat Post 1 54 Fixing Tube 1
13 Seat 1 55 Bolt 2
14 Stopper 4 56 Wheel 2
15 Front Stabilizer 1 57 Bearing 4
16 Main Frame 1 58 Bolt 2 2
17 Handlebar Post 1 59 Fixing Tube 1
18 Handle Bar 1 60 Bearing 2
19 L Shape Knob 1 61 Flywheel 1
20 Flat Washer 1 1 62 Flywheel Shaft 1
21 Locking Knob 1 63 Six Fine-Tuning 1
22 L Shape Knob 1 64 Fine-Tuning Pull Block 1
23 Fixing Nut 2 65 The Brake Fixed Axis 1
24 Fixing Shaft 2 66 Flat Washer 2 2
25 Bolt 3 1 67 Bolt 2 2
26 Fixing Nut 2 2 68 The Brake Block Assembly 1
27 Bolt 4 69 Rubber Mat 1
28 Fixing Nut 1 4 70 End Cap 2 1
29 Crank End Cap 2 71 Woolly Block 1
30 End Cap 2 2 72 Computer 1
31 Lock Nut 6 73 Bolt 3 6
32 Big Gasket 2 74 Sensor 1
33 Left Crank 1 75 Spring Washer 1 2
34 Crank Cover 1 76 Spring Washer 2 4
35 Bearing 2 77 Screw 3 2
36 Right Crank 1 78 Bottle Holder 1
37 Plastic Sleeve 2 79 Bottle 1
38 Pull Out The Fixed Piece 2 80 Pulse 2
39 Fixing Bolt 2 81 Screw 2 2
40 Nut 4 A2 Sensor Wire 1
41 Screw 1 11 B2 Pulse Sensor Wire 1
42 Screw 2 6
