Installation 3.6 Dismantling
Page 44 Operating instructions for S 40-3...S 150-3 series screw compressors
The following compressor oil quantities must be filled into the suction control-
ler:
Tab. 3.2: Compressor oil quantities
2. Screw plug back in again.
3. Turn compressor stage using the pulley by hand 5- to 10 times to spread
the oil evenly.
3.6 Dismantling
Model Compressor oil quantity [gallon]
S 40-3...S 60-3, SF 60-3 approx. 0.13
S 61-3...S 100-3, SF 100-3 approx. 0.66
S 101-3...S 150-3, SF 150-3 approx. 1.32
NOTICE!
To avoid danger when dismantling the compressor, please consult BOGE's
service department:
Telephone: +1-770-874-1570
Telephone: +49 5206 601-140
WARNING!
Dismantling the compressor must only be carried out by authorised and qual-
ified personnel with the necessary experience!
DANGER: High voltage!
All work on the electrical installation must only be carried out by authorised
and skilled electricians!
Prior to starting the work, the power cable to the switch cabinet must be
disconnected from the mains and measures taken to prevent it from being
switched on again unintentionally!
