Bohn Air-Cooled Condensing Units - Unit Specifications

17
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
++ = See Dimensional Drawings for details.
†
= Estimated sound pressure values are 10 feet from the unit. For estimating sound pressure from the unit at
dierent distances, deduct the following from the unit values: 20 feet, deduct 6 dBA for 40 feet, deduct 12 dBA
for 80 feet, deduct 18 dBA. This data is typical of “free eld” conditions for horizontal air cooled condensing units
at the outlet of the discharge air. The actual sound measurements may vary depending on the condensing unit
installation. Factors such as reecting walls, background noise and mounting conditions may have a signicant
inuence on this data.
SEMI-HERMETIC COMPRESSORS
Unit Specifications
Model Fig. ++ Compressor
Connections (ID)
Receiver
90% Full
Lbs.
Fan(s)
Dimensions
Net Wt.
Lbs.
Sound
Data dBA
†
Liquid Suction D (In.) W (In.) H (In.)
BS*005H2 A HAG-0050 3/8 1/2 6.0 1 28.25 23.75 17.25 161 66
BS*008H2 A KAN-0075 3/8 5/8 6.0 1 28.25 23.75 17.25 180 66
BS*008M2 A KAE-0075 3/8 5/8 6.0 1 28.25 23.75 17.25 180 66
BS*010H2 A KAR-0100 3/8 5/8 6.0 1 28.25 23.75 17.25 175 66
BS*010M2 A KAM-0100 3/8 5/8 6.0 1 28.25 23.75 17.25 178 66
BS*015H2 B KAG-0150 3/8 7/8 10.0 2 28.25 37.75 17.25 221 69
BS*020H2 B ERA-0200 3/8 7/8 10.0 2 28.25 37.75 17.25 293 69
BS*020M2 B KAK-0200 3/8 7/8 10.0 2 28.25 37.75 17.25 189 69
BS*021M2 B ERC-0200 3/8 7/8 10.0 2 28.25 37.75 17.25 301 69
BS*029M2 C ERF-0310 1/2 7/8 16.0 2 28.25 37.75 19.75 391 69
BS*030H2 D ERF-0310 1/2 7/8 22.0 1 30.25 42.5 29.75 385 70
BS*030M2 D 3RA-0310 1/2 7/8 22.0 1 30.25 42.5 29.75 397 71
BS*040H2 D NRB-0400 1/2 1-1/8 22.0 1 30.25 42.5 29.75 460 71
BS*050H2 D NRA-0500 1/2 1-1/8 22.0 1 30.25 42.5 29.75 462 71
BS*050M2 D NRM-0500 1/2 1-1/8 22.0 1 30.25 42.5 29.75 462 71
BS*010M6 A KAR-010E 3/8 5/8 5.5 1 28.25 23.75 17.25 178 67
BS*020M6 B KAK-020E 3/8 7/8 9.0 2 28.25 37.75 17.25 189 69
BS*021M6 B ERC-021E 3/8 7/8 9.0 2 28.25 37.75 17.25 301 70
BS*030M6 D ERF-031E 1/2 7/8 20.0 1 30.25 42.5 29.75 397 71
BS*040M6 D NRB-040E 1/2 1-1/8 20.0 1 30.25 42.5 29.75 460 73
BS*010L6 A KAJ-010E 3/8 5/8 5.5 1 28.25 23.75 17.25 178 67
BS*015L6 B KAL-015E 3/8 7/8 9.0 2 28.25 37.75 17.25 225 69
BS*020L6 B EAD-020E 3/8 7/8 9.0 2 28.25 37.75 17.25 291 70
BS*021L6 B EAV-021E 3/8 7/8 9.0 2 28.25 37.75 17.25 301 70
BS*027L6 C 3AB-031E 1/2 7/8 14.0 2 28.25 37.75 19.75 391 71
BS*030L6 C LAH-032E 1/2 7/8 14.0 2 28.25 37.75 19.75 357 71
BS*030E6 C LAC-032E 1/2 7/8 14.0 2 28.25 37.75 19.75 391 71
BS*040L6 D NRD-032/040E 1/2 1-1/8 20.0 1 30.25 42.5 29.75 457 73
