B H T 030 L 6 C F
Model Compressor Application Equiv. HP Temp. Refrigerant Voltage Identier
B =
Bohn
H = Hermetic
S = Semi–herm.
Z = Scroll
T = Outdoor
N = Indoor
S = Beacon II™
Microprocessor
B = Bohnmizer
005 = 1/2 HP
008/009 = 3/4 HP
010, 011 = 1 HP
01* = 1–1/2 HP
02* = 2 HP
03* = 3 HP
04* = 4 HP
05* = 5 HP
060 = 6 HP
H = High
L = Low
M = Medium
E = Extra Low
X = Extended
Medium
2 = R–22
6 = R–404A/507
B = 208/230/1/60
C = 208/230/3/60
D = 460/3/60
G = 230/1/60
F = Stock
Table of Contents
Nomenclature ................................................................................................................................................................................. 2
Features & Benets ........................................................................................................................................................................
3
Options ..............................................................................................................................................................................................4
Hermetic Compressors ................................................................................................................................................................5
Performance Data ...............................................................................................................................................................5
Medium & High Temp., R–22 ................................................................................................................................5
Extended Temp., R–404A/507 ..............................................................................................................................6
Low Temp., R–404A/507 .........................................................................................................................................7
Unit Specication Data. .....................................................................................................................................................7
Electrical Data .......................................................................................................................................................................8
Scroll Compressors ........................................................................................................................................................................9
Performance Data ...............................................................................................................................................................9
Medium Temp., R–404A/507 ................................................................................................................................9
Low Temp., R–404A/507 ...................................................................................................................................... 10
Medium Temp., R–22 ............................................................................................................................................ 11
Low Temp., R–22 .................................................................................................................................................... 12
Unit Specication Data ................................................................................................................................................... 13
Electrical Data .................................................................................................................................................................... 13
Semi–hermetic Compressors .................................................................................................................................................. 14
Performance Data ............................................................................................................................................................ 14
High Temp., R–22 ................................................................................................................................................... 14
Medium Temp., R–404A/507 ............................................................................................................................. 15
Low Temp., R–404A/507 ...................................................................................................................................... 16
Unit Specication Data ................................................................................................................................................... 17
Electrical Data .................................................................................................................................................................... 18
Medium Temp. ........................................................................................................................................................ 18
Low Temp. ................................................................................................................................................................ 19
Replacement Parts by InterLink™ .......................................................................................................................................... 19
Dimensional Drawings of Cabinet ..................................................................................................................................20-21
