Bohn Air-Cooled Condensing Units - Unit Specifications

7
Model Fig. ++ Compressor
Connections (ID)
Receiver
90% Full
Lbs.
Fan(s)
Dimensions
Net Wt.
Lbs.
Sound
Data dBA
†
Liquid Suction D (In.) W (In.) H (In.)
BH*005H2 A ART82C1 3/8 1/2 6.0 1 28.25 23.75 17.25 187 67
BH*008H2 A RS64C2 3/8 1/2 6.0 1 28.25 23.75 17.25 141 68
BH*010H2 A RS70C1 3/8 5/8 6.0 1 28.25 23.75 17.25 136 68
BH*015H2 B CR18KQ 3/8 5/8 10.0 2 28.25 37.75 17.25 189 71
BH*020H2 B CR24KQ 3/8 7/8 10.0 2 28.25 37.75 17.25 193 72
BH*029M2 C CR37KQ 1/2 7/8 16.0 2 28.25 37.75 19.25 214 72
BH*030H2 D CR37KQ 1/2 7/8 22.0 1 30.25 42.50 29.75 281 73
BH*040H2 D CR53KQ 1/2 1-1/8 22.0 1 30.25 42.50 29.75 299 73
BH*050H2 D CRN-0500 1/2 1-1/8 22.0 1 30.25 42.50 29.75 310 75
BH*008X6 A RS55C2E 3/8 1/2 5.5 1 28.25 23.75 17.25 135 68
BH*009X6 A RS64C2E 3/8 5/8 5.5 1 28.25 23.75 17.25 144 68
BH*010X6 A RS70C1E 3/8 5/8 5.5 1 28.25 23.75 17.25 138 68
BH*015X6 B CS10K6E 3/8 5/8 9.0 2 28.25 37.75 17.25 193 71
BH*020X6 B CS12K6E 3/8 7/8 9.0 2 28.25 37.75 17.25 203 73
BH*025X6 B CS14K6E 3/8 7/8 9.0 2 28.25 37.75 17.25 208 74
BH*030X6 D CS18K6E 1/2 7/8 20.0 1 30.25 42.50 29.75 290 73
BH*032X6 D CS20K6E 1/2 7/8 20.0 1 30.25 42.50 29.75 275 76
BH*040X6 D CS27K6E 1/2 1-1/8 20.0 1 30.25 42.50 29.75 281 73
BH*050X6 D CS33K6E 1/2 1-1/8 20.0 1 30.25 42.50 29.75 313 73
BH*011L6 A CF04K6E 3/8 5/8 5.5 1 28.25 23.75 17.25 139 73
BH*014L6 A CF06K6E 3/8 5/8 5.5 1 28.25 23.75 17.25 170 73
BH*019L6 B CF06K6E 3/8 5/8 9.0 2 28.25 37.75 17.25 200 69
BH*025L6 B CF09K6E 3/8 7/8 9.0 2 28.25 37.75 17.25 222 76
BH*031L6 C CF12K6E 1/2 7/8 14.0 2 28.25 37.75 19.75 223 77
HERMETIC COMPRESSORS
Performance Data - Low Temperature (R-404A/507)
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™ ++ = See Dimensional Drawings for details
†
= Estimated sound pressure values are 10 feet from the unit. For estimating sound pressure from the unit at dierent distances, deduct the following from the unit
values: 20 feet, deduct 6 dBA for 40 feet, deduct 12 dBA for 80 feet, deduct 18 dBA. This data is typical of “free eld” conditions for horizontal air cooled condensing
units at the outlet of the discharge air. The actual sound measurements may vary depending on the condensing unit installation. Factors such as reecting walls,
background noise and mounting conditions may have a signicant inuence on this data.
R-404A/507
Model
Compressor
Capacity BTUH @ 90°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
BH*011L6 CF04K6E 7,030 6,240 5,370 3,850 3,330 2,630
BH*014L6 CF06K6E 10,500 9,380 7,830 6,090 4,890 4,080
BH*019L6 CF06K6E 12,100 10,180 8,910 6,580 5,530 4,570
BH*025L6 CF09K6E 15,550 14,500 12,700 9,000 7,560 6,230
BH*031L6 CF12K6E 18,840 17,800 15,140 11,540 9,790 8,070
R-404A/507
Model
Compressor
Capacity BTUH @ 95°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
BH*011L6 CF04K6E 6,840 5,750 4,920 3,650 3,020 2,360
BH*014L6 CF06K6E 9,900 8,840 7,750 5,670 4,710 3,680
BH*019L6 CF06K6E 11,400 10,100 8,750 6,040 5,030 4,150
BH*025L6 CF09K6E 15,400 13,700 12,000 8,300 6,950 5,750
BH*031L6 CF12K6E 17,690 16,800 14,360 10,910 9,170 7,470
R-404A/507
Model
Compressor
Capacity BTUH @ 100°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
BH*011L6 CF04K6E 6,310 5,170 4,460 3,300 2,660 2,070
BH*014L6 CF06K6E 9,310 8,280 7,280 5,280 4,350 3,510
BH*019L6 CF06K6E 10,700 9,430 8,170 5,810 4,570 3,700
BH*025L6 CF09K6E 14,500 12,800 11,200 8,130 6,410 5,220
BH*031L6 CF12K6E 17,600 15,090 13,410 10,700 9,040 7,320
R-404A/507
Model
Compressor
Capacity BTUH @ 110°F Ambient Suction Temperature
0°F -5°F -10°F -20°F -25°F -30°F
BH*011L6 CF04K6E 5,240 4,450 3,620 2,630 2,100 –
BH*014L6 CF06K6E 8,310 7,340 6,420 4,580 3,730 2,990
BH*019L6 CF06K6E 9,330 8,170 7,040 4,920 3,980 3,090
BH*025L6 CF09K6E 12,700 11,400 9,900 7,030 5,760 4,590
BH*031L6 CF12K6E 15,700 14,000 12,400 9,250 7,690 6,100
HERMETIC COMPRESSORS - Unit Specifications
