Bohn Air-Cooled Condensing Units - Electrical Data

8
HERMETIC COMPRESSORS
Electrical Data
* = T for Outdoor, N for Indoor, B for Bohnmizer, S for Beacon II™
Per UL and NEC, RLA values have been calculated by dividing the Maximum Continuous Current (MCC) by 1.56.
^ Power supplied by customer.
†
Consult factory for 50 HZ applications.
Model
Number
Part Number
Power Supply Compressor Fan Motor MCA MOPD
Evap.
Fan
Amps
Defrost
Heater
Amps
Volts Ph Hz
†
RLA LRA Qty. HP FLA Air Elec. Air Elec.
BH*005H2B ART82C1-CAV 208-230 1 60 5.9 30.0 1 1/15 0.5 15.0 20 15 20 8 15
BH*008H2B RS64C2-CAV 208-230 1 60 6.9 37.0 1 1/15 0.5 15.0 20 15 20 8 15
BH*010H2B RS70C1-PFV 208-230 1 60 6.3 34.2 1 1/15 0.5 15.0 20 15 20 7 15
BH*010H2C RS70C1-TFC 208-230 3 60 4.2 31.0 1 1/15 0.5 15.0 20 15 20 8.6 15
BH*015H2B CR18KQ-PFV 208-230 1 60 8.1 41.0 2 1/15 1.0 15.0 24 15 25 6 19
BH*015H2C CR18KQ-TF5 208-230 3 60 4.9 40.0 2 1/15 1.0 15.0 24 15 20 7 19
BH*015H2D CR18KQ-TFD 460 3 60 2.8 23.0 2 1/15 1.0 15.0 20 15 20 ^ ^
BH*020H2B CR24KQ-PFV 208-230 1 60 12.2 70.5 2 1/15 1.0 20.0 29 25 30 6 23
BH*020H2C CR24KQ-TF5 208-230 3 60 6.7 40.0 2 1/15 1.0 15.0 24 15 25 9 19
BH*020H2D CR24KQ-TFD 460 3 60 3.6 28.0 2 1/15 1.0 15.0 20 15 20 ^ ^
BH*029M2B CR37KQ-PFV 208-230 1 60 16.7 100.3 2 1/15 1.0 21.8 38 35 50 12 30
BH*029M2C CR37KQ-TF5 208-230 3 60 9.9 85.0 2 1/15 1.0 15.0 38 20 40 12 30
BH*029M2D CR37KQ-TFD 460 3 60 5.0 39.0 2 1/15 1.0 15.0 15 15 25 ^ ^
BH*030H2B CR37KQ-PFV 208-230 1 60 16.7 100.3 1 1/3 3.5 24.3 38 40 50 12 30
BH*030H2C CR37KQ-TF5 208-230 3 60 9.9 85.0 1 1/3 3.5 20.0 38 25 40 12 30
BH*030H2D CR37KQ-TFD 460 3 60 5.0 39.0 1 1/3 1.9 15.0 24 15 25 ^ ^
BH*040H2B CR53KQ-PFV 208-230 1 60 26.0 140.0 1 1/3 3.5 36.0 48.0 50 60 12 35
BH*040H2C CR53KQ-TF5 208-230 3 60 16.3 107.0 1 1/3 3.5 23.9 38 40 50 12 30
BH*040H2D CR53KQ-TFD 460 3 60 8.1 55.0 1 1/3 1.9 15.0 29 15 30 11 23
BH*050H2B CRN5-0500-PFV 208-230 1 60 30.8 142.0 1 1/3 3.5 42.0 59 50 60 12 47
BH*050H2C CRN5-0500-TF5 208-230 3 60 19.2 130.0 1 1/3 3.5 28.0 40 45 50 12 30
BH*050H2D CRN5-0500-TFD 460 3 60 8.7 65.0 1 1/3 1.9 15.0 29 20 30 10 23
BH*008X6B
RS55C2E-CAV 208-230 1 60 5.4 40.0 1 1/15 0.5 15.0 20 15 20 8 15
BH*009X6B RS64C2E-CAV 208-230 1 60 6.9 37.0 1 1/15 0.5 15.0 20 15 20 7 15
BH*010X6B RS70C1E-PFV 208-230 1 60 6.3 34.2 1 1/15 0.5 15.0 20 15 20 7 15
BH*010X6C RS70C1E-TFC 208-230 3 60 4.2 31.0 1 1/15 0.5 15.0 20 15 20 8.6 15
BH*015X6B CS10K6E-PFV 208-230 1 60 9.8 56.0 2 1/15 1.0 15.0 24 20 25 6 19
BH*015X6C CS10K6E-TF5 208-230 3 60 6.7 51.0 2 1/15 1.0 15.0 20 15 20 7 15
BH*020X6B CS12K6E-PFV 208-230 1 60 9.8 56.0 2 1/15 1.0 15.0 24 20 25 6 19
BH*020X6C CS12K6E-TF5 208-230 3 60 6.7 51.0 2 1/15 1.0 15.0 24 15 25 9 19
BH*025X6B CS14K6E-PFV 208-230 1 60 11.2 61.0 2 1/15 1.0 15.0 29 25 30 6 23
BH*025X6C CS14K6E-TF5 208-230 3 60 8.2 55.0 2 1/15 1.0 15.0 24 15 25 9 19
BH*025X6D CS14K6E-TFD 460 3 60 4.2 28.0 2 1/15 1.0 15.0 20 15 20 ^ ^
BH*030X6B CS18K6E-PFV 208-230 1 60 14.4 82.0 1 1/3 3.5 21.0 38 35 45 12 30
BH*030X6C CS18K6E-TF5 208-230 3 60 9.4 65.5 1 1/3 3.5 15.0 29 20 30 7 23
BH*030X6D CS18K6E-TFD 460 3 60 3.9 33.0 1 1/3 1.9 15.0 24 15 25 ^ ^
BH*032X6B CS20K6E-PFV 208-230 1 60 16.7 96.0 1 1/3 3.5 24.0 38 40 50 12 30
BH*032X6C CS20K6E-TF5 208-230 3 60 10.3 75.0 1 1/3 3.5 20.0 29 25 30 7 23
BH*032X6D CS20K6E-TFD 460 3 60 4.6 40.0 1 1/3 1.9 15.0 24 15 25 ^ ^
BH*040X6B CS27K6E-PFV 208-230 1 60 21.5 121.0 1 1/3 3.5 30.3 44 50 60 12 35
BH*040X6C CS27K6E-TF5 208-230 3 60 13.7 105.0 1 1/3 3.5 20.7 38 30 45 12 30
BH*040X6D CS27K6E-TFD 460 3 60 7.6 52.0 1 1/3 1.9 15.0 29 15 30 11 23
BH*050X6B CS33K6E-PFV 208-230 1 60 27.6 125.0 1 1/3 3.5 38.0 59 50 60 12 47
BH*050X6C CS33K6E-TF5 208-230 3 60 16.8 102.0 1 1/3 3.5 24.5 38 40 50 12 30
BH*050X6D CS33K6E-TFD 460 3 60 8.8 48.0 1 1/3 1.9 15.0 29 20 30 10 23
BH*011L6B
CF04K6E-PFV 208-230 1 60 8.6 59.2 1 1/15 0.5 15.0 20.0 15 25 7 15
BH*011L6C CF04K6E-TF5 200-230 3 60 3.9 52.0 1 1/15 0.5 15.0 20.0 15 20 8 15
BH*014L6B CF06K6E-PFV 208-230 1 60 10.3 59.2 1 1/15 0.5 15.0 20.0 20 25 4 15
BH*014L6C CF06K6E-TF5 200-230 3 60 6.3 52.0 1 1/15 0.5 15.0 24.0 15 25 9 19
BH*025L6B CF09K6E-PFV 208-230 1 60 15.0 87.0 2 1/15 1.0 20.0 29.0 30 40 6 23
BH*025L6C CF09K6E-TF5 200-230 3 60 9.2 72.2 2 1/15 1.0 15.0 21.0 20 25 7 15
BH*031L6B CF12K6E-PFV 208-230 1 60 17.0 105.0 2 1/15 1.0 22.3 37.5 35 50 12 30
BH*031L6C CF12K6E-TF5 200-230 3 60 10.7 85.0 2 1/15 1.0 15.0 28.8 25 30 7 23
BH*031L6D CF12K6E-TFD 460 3 60 5.3 42.0 2 1/15 1.0 15.0 23.8 15 25 ^ ^
