WARNING!
Danger of accident!
As a measure to avoid injury the machine must only be
guided from the side by the steering handle
Pull the travel lever Ä Fig. 29 back, until the vibratory plate
has reached the desired speed in reverse.
The machines vibrates backwards with a speed which corresponds
to the travel lever position.
Move the travel lever Ä Fig. 30 to middle position, the
machine will vibrate on the spot.
Keep shifting the throttle lever Ä
Fig. 31 between "MIN" and
"MAX" positions.
At the same time pull the vibratory plate by the steering rod
to the right and left, until it comes free.
Drive backwards
Fig. 29
Vibration on the spot
Fig. 30
If the vibratory plate got stuck
Fig. 31
Operation – Work/operation
BPR 50/55 D / BPR 60/65 D
43
