BOMBARDIER outlander max series User Manual

104
32) Winch Control Switch
XT Models
Located on the left side of the handlebar, over
direction indicator switch.
To take out wire rope from winch, press the
left side of switch.
To get wire rope into the winch, press the right
side of switch.
Refer to ATV Winch Operator's manual for
more informations.
1. In
2. Out
33) Fairlead
XT Models
Located on the front of skid plate.
The fairlead is used to prevent the damages
to the vehicle and guide the wire rope into the
winch.
1. Front skid plate
2. Fairlead
3. Winch hook

WARNING
The front winch hook of the so equipped ve-
hicles must be removed and stored when
riding the vehicle on public trails and/or
roads.
Failure to do so can increase the risk of in-
jury to bystanders.
V07G22Z
2 1
V07A0PZ
1
3
2
