BOMBARDIER outlander max series User Manual

89
TYPICAL
1. Headlamp switch
2. Low beam position
3. High beam position
NOTE: Place ignition switch to ON "without
light" position to close the headlamp.
ON POSITION WITHOUT LIGHT
Engine Stop Switch
Located at the middle of multi-function switch.
The engine will turn over but will not start if the
engine stop switch is turned to OFF position.
TYPICAL
1. Engine stop switch
This switch can be used to stop engine and
as an emergency control.
NOTE: While engine can be stopped by turn-
ing ignition key OFF, we recommend the en-
gine be stopped by the engine stop switch.
To stop engine, fully release throttle lever then
use the engine stop switch.
1
V07I03Y
3 2
V07A1IY
V07I05Y
1
