Boneco H320 - Overview and Part Names

9
en
OVERVIEW AND PART NAMES
1
2
3
4
5
7 8 96
1 Cover/air inlet
2 Pre-filter
3 AH320 pollen filter
4 Hygrostat opening
5 On/O, knob
6 Air outlet
7 Fragrance container
8 Water base*
9 Float gage*
10 Drum*
11 AW200 evaporator mat**
1110
* Washable in the dishwasher up to
122°F (50°C)
** Washable in the washing machine
up to 104°F (40°C)
