Identify the attachment points for lifting the gear unit. Refer to the diagrams given below.
Horizontal positions
317 L ... 325 L , 317M L , 318M L
300 L ... 316 L , 310M L ... 316M L
Ring harness
Screw clamp (use with
harness)
Maximum permissible tilt during
handling: 15°
Rope and hooks
Snap hook (use with rope)
Open harrness with
eyelets
Eyebolt (already  tted on gear
units 317-325 , 317M , 318M)
