BONFIGLIOLI 309 User Manual

16 / 52
300 L ... 325 L , 310M L ... 318M L
3A 00 ... 3A 07
300 R ... 321 R , 310M R ... 318M R
3V 00 ... 3V 21 , 3V 10M ... 3V 18M
Ring harness
Screw clamp (use with
harness)
Maximum permissible
tilt during handling: 15°
Rope and hooks
Snap hook (use with rope)
Open harrness with
eyelets
Eyebolt (already  tted on gear
units 317-325 , 317M , 318M)
Vertical positions
