BONFIGLIOLI 309 User Manual

44 / 52
B0 U_ P_
300
R2 1.2 1.7 1.5
R3 1.5 2.0 1.8
R4 1.8 2.3 2.1
301
R2 1.6 2.1 1.9
R3 1.9 2.4 2.2
R4 2.2 2.7 2.5
303
R2 2.2 2.8 2.6
R3 2.5 3.1 2.9
R4 2.8 3.4 3.2
304
R2 2.3 2.9 2.7
R3 2.8 3.4 3.2
R4 3.1 3.7 3.5
305
R2 2.5 3.1 2.9
R3 3.0 3.6 3.4
R4 3.3 3.9 3.7
306
R2 4.0 5.0 4.8
R3 4.8 5.8 5.6
R4 5.1 6.1 5.9
307
R2 6.0 8.0 7.0
R3 7.0 9.0 8.0
R4 7.5 9.5 8.5
309
R2 6.5 8.5 7.5
R3 7.5 9.5 8.5
R4 8.0 10 9.0
B0 U_ P_
310
310M
R2 13 15 14
R3 11 13 12
R4 12 14 13
311
311M
R2 14 19 17
R3 16 21 19
R4 17 22 20
313
313M
R2 16 21 19
R3 19 24 22
R4 20 25 23
314
314M
R3 25 33 29
R4 28 36 32
315
315M
R3 27 35 31
R4 30 38 34
316
316M
R3 30 38 34
R4 33 41 37
317
317M
R3 38 52 48
R4 42 56 52
318
318M
R4 48 63 58
319
R4 55 70 65
321
R4 60 75 70
Mounting position Mounting position
3_R Series
N.B. Oil quantities are indicative. Check actual level after lling through the appropriate plug.
