BONFIGLIOLI BX Series User Manual

12 / 32
IOM BX-BE-BN-MX-ME-M_eng - Translation of original instructions in Italian - Rev 02_0 - 30/09/16
Check the air gap periodically and re-adjust it if dimension T is found exceeding the min/max values
indicated in diagram.
Particularly, brake may become noisier if gap is wider than the max value. In extreme cases releasing
of the brake might also be affected.
If the brake disengagement device is tted, too wide a gap may lead the braking torque to
drop signicantly as a consequence of the reduced play in the release mechanism.
Distance “X” must mandatorily be equal to or greater than the value listed in the chart.
Thickness of disc lining must always be greater than 1.5 mm.
FD
FD 02 FD 03
FD 53
FD 04
FD 14
FD 05
FD 15
FD 55
FD 06S FD 06
FD 56
FD 07 FD 08
FD 09
FA
FA 02 FA 03 FA 04
FA 14
FA 05
FA 15
FA 06S FA 06 FA 07 FA 08
T
X
Min 0.2
0.5
0.8
0.2
0.5
0.8
0.3
0.6
1.0
0.3
0.6
1.0
0.35
0.7
1.1
0.35
0.7
1.1
0.4
0.8
1.2
0.5
1.0
1.5
Max
BN 71 ... BN 100 - BE 80 ... BE 100 - BX 80 ... BX 100
M1 ... M3 - ME2, ME3 - MX2, MX3
BRAKE TYPE
T (mm) = Air gap
FA 02 3.5
FA 03 7.5
FA 04 15
FA 14 15
FA 05 40
FA 15 40
FA 06S 60
FA 06 75
FA 07 150
FA 08 250
BRAKE Max. brake torque
