ANNEX 2 - LUBRICANT FILL QUANTITY

Helical in-line gear units, series C:

PFU-UF

B3 B6 B7 B8 V5 V6 B5 B51 B53 B52 V1 V3 B5 B51 B53 B52 V1 V3

C052 0.35 0.35 0.35 0.35 0.35 0.35 0.35 0.35 0.35 0.35 0.35 0.35 - - - - - -

C112 0.45 0.45 0.45 0.45 0.50 0.60 0.40 0.40 0.50 0.50 0.50 0.60 0.40 0.40 0.50 0.50 0.50 0.60

C212 0.80 0.80 0.80 0.80 0.85 1.1 0.75 0.75 0.75 0.75 0.80 1.0 0.75 0.75 0.75 0.75 0.80 1.0

C213 1.2 1.2 1.2 1.2 1.3 1.4 1.2 1.2 1.2 1.2 1.3 1.4 1.2 1.2 1.2 1.2 1.3 1.4

C312 1.4 1.4 1.4 1.4 1.5 1.5 1.3 1.3 1.3 1.3 1.5 1.5 1.3 1.3 1.3 1.3 1.5 1.5

C313 1.6 1.6 1.6 1.6 1.8 1.8 1.6 1.6 1.6 1.6 1.8 1.8 1.6 1.6 1.6 1.6 1.8 1.8

C352 1.61.51.51.32.12.4------1.61.51.51.32.12.4

C353 1.51.41.51.32.02.3------1.51.41.51.32.02.3

C354 2.32.12.32.12.73.1------2.32.12.32.12.73.1

C412 2.22.02.11.92.73.4------2.22.02.11.92.73.4

C413 2.11.92.11.92.63.2------2.11.92.11.92.63.2

C414 2.82.62.82.63.53.9------2.82.62.82.63.53.9

C512 3.13.03.13.04.35.0------3.13.03.13.04.35.0

C513 3.02.83.13.04.14.9------3.02.83.13.04.14.9

C514 4.34.14.44.25.46.1------4.34.14.44.25.46.1

C612 4.24.04.24.16.06.7------4.24.04.24.16.06.7

C613 4.24.04.24.16.06.7------4.24.04.24.16.06.7

C614 6.15.96.16.07.98.6------6.15.96.16.07.98.6

C702 6.5 8.5 8.5 7.5 11 7.5 6.5 8.5 8.5 7.5 11 7.5 - - - - - -

C703 6.5 8.5 8.5 7.5 11 7.5 6.5 8.5 8.5 7.5 11 7.5 - - - - - -

C704 6.5 8.5 8.5 7.5 11 8.0 6.5 8.5 8.5 7.5 11 7.5 - - - - - -

C802 11 14 14 13 18 13 11 14 14 13 18 13 - - - - - -

C803 11 14 14 13 18 13 11 14 14 13 18 13 - - - - - -

C804 11 14 14 13 18 13 11 14 14 13 18 13 - - - - - -

C902 19 25 25 22 31 22 19 25 25 22 31 22 - - - - - -

C903 19 25 25 22 31 22 19 25 25 22 31 22 - - - - - -

C904 19 25 25 22 31 22 19 25 25 22 31 22 - - - - - -

C 100 2 27 37 37 33 45 33 27 37 37 33 45 33 - - - - - -

C 100 3 27 37 37 33 45 33 27 37 37 33 45 33 - - - - - -

C 100 4 27 37 37 33 45 33 27 37 37 33 45 33 - - - - - -

(A9)

oil

[l]

Life-time lubricated gear units.

Life-time lubricated gear units only in combination with ATEX variants.

Lubricant is not factory filled.
