BONNET GRANDE CUISINE
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex

0000
: Changeable PIN Code
CHEF
: Password « permanent »
(Upper or lower case)

For a personalised code in text format it is possible to switch the keypad to and from
alpha numeric
21 WATER FILL MENU
Attention
:
For your safety it is impossible to use this water supply button:
- in FRYER mode
- in all modes if the well temperature probe registers over 130°C.
Cold water supply (by defaut)
Allows for filling and cleaning of the well
Briefly touching this button displays the water fill menu.
A longer press (over a second) allows water filling without displaying the menu. A second long press
stops the water fill

Set the volume of water and press the "START" button
Pressing START without having selected a volume starts a manual fill without an automatic stop
(the counter shows how much water has gone into the well)
Or

Select a pre-programmed capacity and press the "START" button

Bar graph to select the type of water by moving the tap icon but only if the unit is connected to
hot and cold water and the ‘Hot water’ option has been validated in the Installation parameters
menu
3 Positions : Hot water / Hot + Cold water / Cold water
22 DRAIN MENU
Allows the well to be drained via the drain outlet
Briefly touching this button allows the drain to open
A second press closes it
The drain outlet closes automatically after 4 minutes if the screen is not touched again.
23 WELL TILT MENU
Attention
:
It is not possible to tilt the well if:
- the cover is not in the open position
- the basket lift bar (optional) is fitted to the unit.
Using the tilt whilst cooking automatically stops the cooking cycle
It is impossible to start cooking if the well is not fully lowered (horizontal)
