3B-490033NU – 10/19 Page 7
BONNET GRANDE CUISINE
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
Stop the water feed
Tilt the well into the drain position
- Finish the rinse with the spray hose
25 OPTIONAL BASKET LIFT
Fitting the basket lift arm
- Open the lid.
- Engage the arm on each side of the lid axis.
Using the basket lift
Attention: Respect the 8 kilogram maximum load for finished product per basket. Take into account the
increase in weight of dry product as it cooks.
- Locate the basket lift arm.
- Fit the basket(s)
-
Fit up to 2 or 3 GN 1/1 150mm deep baskets (depending on the model).
- Select the cooking method (Boiling pan or fryer)
- Set a temperature
- Set the desired cooking time.
Allows adjustment of the immersion time for the baskets. The process is started
by pressing the basket lift button.
The immersion time is displayed until the button is pressed then the
cooking time is displayed.
When the cooking time hits 0:
- The baskets will lift automatically
- Set cooking time will be displayed again
Note: Pressing the ‘Immersion’ button without inputting a time starts a manual lift cycle when the ‘lift’ button is pressed (the counter indicates the time
that the baskets have been immersed)
Note: The lift arm cannot be lowered if either of these two things has not been done:
- The lid must be in the fully open position.
- The well must be lowered (horizontal).
Note: Using the baskets guarantees product quality, avoiding the need to manually unload the unit during which delicate products (petit pois...) can be
spoiled.
