ENBoretti Ibrido / User guide - Installation advice
3. Assembly instructions
Step 1
Remove the pan support and unscrew the 2 M4x5 screws to unfasten the side burner.
2x M6 screw
2x M6 screw
fig. 1
Step 2 - a) Loosen 4 screws on the right side of the fire basket by about 6 mm.
b) Slide the side burner with the cut-outs over the screws that you have
loosened.
c) Then tighten the 4 screws again to secure the side burner.
d) Connect the gashose to the gastube. See fig.1.
2x M6 screw
2x M6 screw
fig. 1
