UPS user manual
Utilizzo dell’UPS
OMS02083 REV. A 33
7 SYSTEM INFORMATION
The INFO menu provides general information regarding the UPS based on the structure
indicated below.
All data shown in the various sections are set by the factory via a special interface software
and cannot be altered, except by personnel authorized by the manufacturer.
The only adjustable parameters are the MODBUS settings (see SPECIAL menu).
Sub-menu Displayed data
SERIAL NUMBER
Device serial number given by the manufacturer and
by an OEM distributor, if any
DEVICE TYPE
The device type can be:
ON LINE - UPS
FREQUENCY CONVERTER
ECO MODE - UPS
SINGLE UPS
PARALLEL
PARALLEL
(1)
Data regarding the parallel configuration
MODBUS
MODBUS address of device
FIRMWARE RELEASE
Firmware versions installed on the system
SERVICE
Scrolling text string with information regarding
technical service
RUNNING HOURS
Dates related to hours number of UPS running time
(1)
the menu is only active if the UPS belongs to a Parallel or Load Sync system
7.1 PARALLEL OPERATION INFORMATION
The PARALLEL menu is only active if the UPS belongs to a parallel or load-sync system.
7.1.1 UPS position and Master / Slave priority
The first number on the first line identifies the position of that specific UPS within the parallel
system. The second number represents the total number of UPS units.
