Installation and start-up of INGENIO PLUS UPS 30÷40 kVA
Installazione e avviamento INGENIO PLUS UPS 30÷40 kVA
18 OMS02082 REV. D
3.2 HANDLING OF THE UPS
The UPS is packed on a pallet. It is handled from the transport vehicle to the installation (or
storage) place via a fork lift.
The device has a heavy weight
Avoid turnover during the transport of the UPS.
Cabinets must always be handled in upright position.
During loading and unloading operations, always respect the indications
regarding the device barycentre marked on the package.
Before positioning the UPS, in order to avoid risks of turnover, it’s recommended to move the
system on the wood pallet on which the UPS is fixed.
Before the positioning in the final location, remove the UPS from the pallet.
Handling of the UPS
The UPS INGENIO PLUS 30÷40 kVA can be handled by means of the four wheels
fixed on the bottom.
Picture 2 – Handling of the INGENIO PLUS UPS 30÷40 kVA
